DNV F550 shipbuilding steel plate, NV F550 shipbuilding steel plate, DNV F550 shipbuilding angle steel bar
NV F550 shipbuilding steel with good toughness properties,higher strength.NV F550 offshore engineering steel are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.All of our stock is the high quality NV F550 shipbuilding steel plate.Shanghai Royal Industry has a large number of stocks.
DNV F550, NV F550 DNV F550 Z15, DNV F550 Z25,DNV F550 Z35
chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
C max |
Si |
Mn max |
P max |
S max |
Als |
N max |
Nb max |
V max |
Ti max |
B max |
|
F550 |
0.21 |
0.10-0.55 |
1.7 |
0.035 |
0.035 |
0.015-0.08 |
0.20 |
0.02-0.05 |
0.04-0.10 |
0.02 |
0.005 |
DNV F550, NV F550 DNV F550 Z15, DNV F550 Z25,DNV F550 Z35
Mechanical Property in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
Mechanical Property |
Charpy V Impact Test |
||||
|
Yield Min Mpa |
Tensile Mpa |
Elongation Min % |
Degree |
Energy 1 (J) |
Energy 2(J) |
|
|
F550 |
550 |
670-830 |
16% |
-60 |
37 |
55 |
DNV F550, NV F550 DNV F550 Z15, DNV F550 Z25,DNV F550 Z35
shipbuilding steel plate, Delivery condition: CR, Normalized, Q&T, TMCP, Impact test. Z15, Z25, Z35
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled DNV F550, NV F550 shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find DNV F550, NV F550 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, DNV F550, NV F550 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, DNV F550, NV F550 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact Shanghai Royal Industry’s sales team. We will give you the DNV F550, NV F550 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, DNV F550, NV F550 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
Related Link:DNV A550, DNV D550, DNV E550,Extra-high strength shipbuilding steel plate
