GL D690 shipbuilding steel plate, GL-D690 shipbuilding steel plate, GL D690 shipbuilding angle steel bar
GL D690 with good toughness properties,higher strength.GL D690 are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.All of our stock is the high quality GL D690 shipbuilding steel plate.Shanghai Royal Industry has a large number of stocks.
GL D690, GL-D690 GL D690 Z15, GL D690 Z25,GL D690 Z35
chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
C max |
Si |
Mn max |
P max |
S max |
Als |
N max |
Nb max |
V max |
Ti max |
B max |
|
D690 |
0.21 |
0.10-0.55 |
1.7 |
0.035 |
0.035 |
0.015-0.08 |
0.20 |
0.02-0.05 |
0.04-0.10 |
0.02 |
0.005 |
GL D690, GL-D690 GL D690 Z15, GL D690 Z25,GL D690 Z35
Mechanical Property in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
Mechanical Property |
Charpy V Impact Test |
||||
|
Yield Min Mpa |
Tensile Mpa |
Elongation Min % |
Degree |
Energy 1 (J) |
Energy 2(J) |
|
|
D690 |
690 |
770-940 |
14% |
-20 |
46 |
69 |
GL D690, GL-D690 GL D690 Z15, GL D690 Z25,GL D690 Z35
shipbuilding steel plate, Delivery condition: CR, Normalized, Q & T, TMCP, Impact test. Z15, Z25, Z35
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled GL D690, GL-D690 shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL D690, GL-D690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL D690, GL-D690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL D690, GL-D690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact Shanghai Royal Industry’s sales team. We will give you the GL D690, GL-D690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL D690, GL-D690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
