GL E690 shipbuilding steel plate, GL-E690 shipbuilding steel plate, GL E690 shipbuilding angle steel bar
GL E690 shipbuilding steel is a kind of high tensile strength marine steel. All of these steels have been engineered to be optimal long-lived shipbuilding steels.GL E690 Shipbuilding steel plates are mainly used for making the offshore oil drilling platform, the hull of ship building and ship repairing, the platform pipe joints and other components. All the GL E690 shipbuilding Steel offered by Shanghai Royal Industry can be certificated by Shanghai Royal Industry as per customer's request.
GL E690, GL-E690 GL E690 Z15, GL E690 Z25,GL E690 Z35
chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
C max |
Si |
Mn max |
P max |
S max |
Als |
N max |
Nb max |
V max |
Ti max |
B max |
|
E690 |
0.21 |
0.10-0.55 |
1.7 |
0.035 |
0.035 |
0.015-0.08 |
0.20 |
0.02-0.05 |
0.04-0.10 |
0.02 |
0.005 |
GL E690, GL-E690 GL E690 Z15, GL E690 Z25,GL E690 Z35
Mechanical Property in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
Mechanical Property |
Charpy V Impact Test |
||||
|
Yield Min Mpa |
Tensile Mpa |
Elongation Min % |
Degree |
Energy 1 (J) |
Energy 2(J) |
|
|
E690 |
690 |
770-940 |
14% |
-40 |
46 |
69 |
GL E690, GL-E690 GL E690 Z15, GL E690 Z25,GL E690 Z35
shipbuilding steel plate, Delivery condition: CR, Normalized, Q&T, TMCP, Impact test. Z15, Z25, Z35
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled GL E690, GL-E690 shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL E690, GL-E690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL E690, GL-E690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL E690, GL-E690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact Shanghai Royal Industry's sales team. We will give you the GL E690, GL-E690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL E690, GL-E690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
