GL F690 shipbuilding steel plate, GL-F690 shipbuilding steel plate, GL F690 shipbuilding angle steel bar
GL F690 with good toughness properties,higher strength.GL F690 are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.All of our stock is the high quality GL F690 shipbuilding steel plate.Shanghai Royal Industry has a large number of stocks.
Key words: GL F690 shipbuilding steel, GL F690 Ocean steel, GL F690 Marine steel,GL F690 Z15, GL F690 Z25,GL F690 Z35,ASTM A131 GL F690
GL F690, GL-F690 GL F690 Z15, GL F690 Z25,GL F690 Z35
chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
C max |
Si |
Mn max |
P max |
S max |
Als |
N max |
Nb max |
V max |
Ti max |
B max |
|
F690 |
0.21 |
0.10-0.55 |
1.7 |
0.035 |
0.035 |
0.015-0.08 |
0.20 |
0.02-0.05 |
0.04-0.10 |
0.02 |
0.005 |
GL F690, GL-F690 GL F690 Z15, GL F690 Z25,GL F690 Z35
Mechanical Property in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
Mechanical Property |
Charpy V Impact Test |
||||
|
Yield Min Mpa |
Tensile Mpa |
Elongation Min % |
Degree |
Energy 1 (J) |
Energy 2(J) |
|
|
F690 |
690 |
770-940 |
14% |
-60 |
46 |
69 |
GL F690, GL-F690 GL F690 Z15, GL F690 Z25,GL F690 Z35
shipbuilding steel plate, Delivery condition: CR, Normalized, Q&T, TMCP, Impact test. Z15, Z25, Z35
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled GL F690, GL-F690 shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL F690, GL-F690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL F690, GL-F690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL F690, GL-F690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact Shanghai Royal Industry's sales team. We will give you the GL F690, GL-F690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL F690, GL-F690 shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
Related Link : GL FH70 , LR FH69, BV F690, DNV F690, KR F70, NK F70, RINA F690,LR certification shipbuilding steel
