API 2WGr50 shipbuilding steel,API 2W Grade 50 Marine steel, API 2WGr50 offshore engineering steel
0 shipbuilding steel, 2W Grade 50 Ocean steel, with good toughness properties,higher strength.API 2WGr50 shipbuilding steel are mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.All of our stock is the high quality API 2WGr50 shipbuilding steel plate.Shanghai Royal Industry has a large number of stocks.
API 2WGr50 shipbuilding steel plate chemical composition
|
Grade |
C max |
Si |
Mn |
P max |
S max |
Nb max |
Ti max |
Al |
N max |
Ni max |
Cr max |
Mo max |
Cu max |
B max |
|
2WGr50 |
0.16 |
0.05- 0.50 |
1.15-1.60 |
0.030 |
0.010 |
0.015 |
|
0.015-0.055 |
0.012 |
0.75 |
0.25 |
0.08 |
0.35 |
0.0005 |
API 2WGr50 Ocean structural steel plate , steel plate for Ocean construction Mechanical Property
|
Grade |
Rm (MPa) |
Re(MPa) min |
Delivery condition |
|
2WGr50 |
400-520 |
235 |
TMCP |
API 2WGr50 Ocean structural steel plate , steel plate for Ocean construction Carbon equivalent
|
Grade |
Thickness of plates |
EC max |
|
2WGr50 |
≤40mm/1.5 in |
0.39 |
|
＞40mm/1.5 in-90mm/3.5in |
0.41 |
|
|
＞90mm/3.5in-150mm/4 in |
0.43 |
API 2WGr50 Ocean structural steel plate , steel plate for Ocean construction impact test and energy
|
Grade |
Items |
Sample Size in. |
Sample Size mm |
Min Energy ft-lb(J) |
Unit Min Energy ft-lb(J) |
Test temperature °F(°C） |
|
2WGr50 |
A |
0.394*0.394 |
10*10 |
30(41) |
25(34) |
-40(-40) |
|
B |
0.295*0.394 |
7.5*10 |
30(41) |
25(34) |
40(-40) |
|
|
C |
0.197*0.394 |
5.0*10 |
30(41) |
25(34) |
40(-40) |
|
|
D |
0.295*0.394 |
7.5*10 |
23(31) |
19(26) |
50(-46) |
|
|
E |
0.197*0.394 |
5.0*10 |
15(20) |
13(18) |
80(-62) |
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and API 2WGr50 shipbuilding steel in stock each month. We can meet our customer's any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find API 2WGr50 Ocean structural steel plate supplier, API 2WGr50 shipbuilding steel plate manufacturer, API 2W Grade 50 shipbuilding steel plate exporter, please contact Shanghai Royal Industry's sales team. We will give you the API 2WGr50 shipbuilding steel plate competitive price, API 2WGr50 Ocean structural steel plate good quality and best service from us.
