API 2WGr60 shipbuilding steel plate, API 2W Grade 60 shipbuilding steel plate, 2WGr60 structural steel plate
API 2W Grade 60 Marine steel is a kind of high tensile strength marine steel. All of these steels have been engineered to be optimal long-lived shipbuilding steels.API 2WGr60 shipbuilding steel plates are mainly used for making the offshore oil drilling platform, the hull of ship building and ship repairing, the platform pipe joints and other components. All the API 2WGr60 shipbuilding steel offered by Shanghai Royal Industry can be certificated by Shanghai Royal Industry as per customer's request.
API 2WGr60 shipbuilding steel plate chemical composition
|
Grade |
C max |
Si |
Mn |
P max |
S max |
Nb max |
Ti max |
Al |
N max |
Ni max |
Cr max |
Mo max |
Cu max |
B max |
|
2WGr60 |
0.16 |
0.05- 0.50 |
1.15-1.60 |
0.030 |
0.010 |
0.015 |
|
0.015-0.055 |
0.012 |
1.0 |
0.25 |
0.15 |
0.35 |
0.0005 |
API 2WGr60 Ocean structural steel plate , steel plate for Ocean construction Mechanical Property
|
Grade |
Rm (MPa) |
Re(MPa) min |
Delivery condition |
|
2WGr60 |
400-520 |
235 |
TMCP |
API 2WGr60 Ocean structural steel plate , steel plate for Ocean construction Carbon equivalent
|
Grade |
Thickness of plates |
EC max |
|
2WGr60 |
≤40mm/1.5 in |
0.42 |
|
＞40mm/1.5 in-100mm/4in |
0.45 |
API 2WGr60 Ocean structural steel plate , steel plate for Ocean construction impact test and energy
|
Grade |
Items |
Sample Size in. |
Sample Size mm |
Min Energy ft-lb(J) |
Unit Min Energy ft-lb(J) |
Test temperature °F(°C） |
|
2WGr60 |
A |
0.394*0.394 |
10*10 |
35(48) |
30(41) |
-40(-40) |
|
B |
0.295*0.394 |
7.5*10 |
35(48) |
30(41) |
40(-40) |
|
|
C |
0.197*0.394 |
5.0*10 |
35(48) |
30(41) |
40(-40) |
|
|
D |
0.295*0.394 |
7.5*10 |
26(35) |
23(31) |
50(-46) |
|
|
E |
0.197*0.394 |
5.0*10 |
18(24) |
15(20) |
80(-62) |
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and API 2WGr60 shipbuilding steel in stock each month. We can meet our customer's any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find API 2WGr60 Ocean structural steel plate supplier, API 2WGr60 shipbuilding steel plate manufacturer, API 2W Grade 60 shipbuilding steel plate exporter, please contact Shanghai Royal Industry's sales team. We will give you the API 2WGr60 shipbuilding steel plate competitive price, API 2WGr60 Ocean structural steel plate good quality and best service from us.
