GL Grade A shipbuilding steel plate,GL Grade A shipbuilding angle steel bar

GL grade A Ocean steel

GL-A shipbuilding steel with good toughness properties,higher strength.GL-A shipbuilding steel are mainly used to contribute hull of ships and the cranes of breaGL-AulkeGL-And vessels in low temperature oceans.All of our stock is the high quality GL-A shipbuilding steel plate.Shanghai Royal Industry has a large number of stocks.

GL grade A Marine steel chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar

Grade

C max

Si max

Mn

P max

S max

Als min

GL-A

0.21

0.50

≥ 2.5C

0.035

0.035

-

CE: C+1/6Mn ≤ 0.40%

Cu ≤ 0.35%,Ni ≤ 0.30%

GL Grade A, GL-A Mechanical Property in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar

Grade

Rm

(MPa)

Re(MPa) min

A% min

Akv/J min

E.T °C

Thickness (mm)

≤ 50

>50-70

>70-100

L

C

L

C

L

C

GL-A

400-520

235

22

20

-

-

34

24

41

27



GL Grade A, GL-A shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade

category

The thickness of steel




≤ 12

>12.5-25

>25-35

>35-50

>50-100

GL-A

Plate/sheet

A(-)

N(-),TM(-)

CR(50)

AR*(50)

Profile steel



-

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled GL Grade A, GL-A shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL Grade A, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL Grade A, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL Grade A, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact Shanghai Royal Industry’s sales team. We will give you the GL Grade A, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL Grade A, GL-A shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
