GL Grade E shipbuilding steel plate,GL Grade E shipbuilding angle steel bar
GL-E shipbuilding steel plate with good toughness properties,higher strength.GL-E shipbuilding steel are mainly used to contribute hull of ships and the cranes of breaGL-EulkeGL-End vessels in low temperature oceans.All of our stock is the high quality GL-E shipbuilding steel plate.Shanghai Royal Industry has a large number of stocks.
GL Grade E chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
C max |
Si max |
Mn |
P max |
S max |
Als min |
|
GL-E |
0.18 |
0.35 |
0.70-1.20 |
0.035 |
0.035 |
0.015 |
CE: C+1/6Mn ≤ 0.40%
Cu ≤ 0.35%,Ni ≤ 0.30%
GL Grade E, GL-E Mechanical Property in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
Rm (MPa) |
Re(MPa) min |
A% min |
Akv/J min |
||||||
|
E.T °C |
Thickness (mm) |
|||||||||
|
≤ 50 |
>50-70 |
>70-100 |
||||||||
|
L |
C |
L |
C |
L |
C |
|||||
|
GL-E |
400-520 |
235 |
22 |
-40 |
27 |
20 |
34 |
24 |
41 |
27 |
GL Grade E, GL-E shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar delivery condition :
|
Grade |
category |
The thickness of steel |
||||
|
≤ 12 |
>12.5-25 |
>25-35 |
>35-50 |
>50-100 |
||
|
E |
Plate/sheet |
N,TM |
||||
|
Profile steel |
N(25),TM(25),AR*(15),CR*(15) |
- |
||||
Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled GL Grade E, GL-E shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.
We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL Grade E, GL-E shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL Grade E, GL-E shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL Grade E, GL-E shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact Shanghai Royal Industry's sales team. We will give you the GL Grade E, GL-E shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL Grade E, GL-E shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
Related Link: GL Grade A, GL Grade B, GL Grade D,Ordinary-strength shipbuilding steel plate
