GL Grade D shipbuilding steel plate,GL Grade D shipbuilding angle steel bar

GL-D shipbuilding steel with good toughness properties,higher strength.GL-D shipbuilding steel are mainly used to contribute hull of ships and the cranes of breaGL-DulkeGL-Dnd vessels in low temperature oceans.All of our stock is the high quality GL-D shipbuilding steel plate.Shanghai Royal Industry has a large number of stocks.

GL Grade D offshore engineering steel chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar

Grade	C max	Si max	Mn	P max	S max	Als min
GL-D	0.21	0.35	0.60-1.20	0.035	0.035	0.015

CE: C+1/6Mn ≤ 0.40%

Cu ≤ 0.35%,Ni ≤ 0.30%

GL Grade D, GL-D Mechanical Property in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
				E.T °C	Thickness (mm)
					≤ 50		>50-70		>70-100
					L	C	L	C	L	C
GL-D	400-520	235	22	-20	27	20	34	24	41	27

GL Grade D, GL-D shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar delivery condition :

Grade	category	The thickness of steel
		≤ 12	>12.5-25	>25-35	>35-50	>50-100
D	Plate/sheet	A(50)			N(50) CR(50) TM(50)	N(50) TM(50) CR(25)
	Profile steel				N(50) CR(50) TM(50) AR*(25)	-

Shanghai Royal Industry keeps more than 10,000 tons hot rolled and cold rolled GL Grade D, GL-D shipbuilding steel in stock each month. We can meet our customer’s any quantity request. Based on these stock source, our advantage industry spread into steel process like : cutting ( any size and any shape ) drilling, welding, milling, machining and steel structure.

We also have a high quality logistics team who make sure the fast delivery time and shipment. Anyway, if you want to find GL Grade D, GL-D shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar supplier, GL Grade D, GL-D shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar manufacturer, GL Grade D, GL-D shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar exporter, please contact Shanghai Royal Industry‘s sales team. We will give you the GL Grade D, GL-D shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar competitive price, GL Grade D, GL-D shipbuilding steel plate/sheet/angle bar/bulb flat bar/ L section steel bar good quality and best service from us.
